Specifications

• ENGINE

  add remove
  • Engine Type:
    V Twin
  • Cylinders:
    2
  • Engine Stroke:
    4-Stroke
  • Cooling:
    Air
  • Valves:
    8
  • Valves Per Cylinder:
    4
  • Valve Configuration:
    OHV - Pushrod
  • Bore (in):
    3.94
  • Stroke (in):
    4.65
  • Displacement (cc):
    1854
  • Fuel Injector:
    Yes
  • Carburetor:
    No
  • Carburetion Type:
    Fuel Injected
  • Turbocharged:
    No
  • Supercharged:
    No
  • Torque RPM:
    2500
  • Compression ratio:
    9.5:1
• TRANSMISSION

  add remove
  • Transmission Type:
    Manual
  • Number Of Speeds:
    5
  • Overdrive:
    Yes
  • Primary Drive (Rear Wheel):
    Belt
  • Reverse:
    No
• TECHNICAL SPECIFICATIONS

  add remove
  • Length (in):
    101.2
  • Width (in):
    36.4
  • Height (in):
    45.9
  • Wheelbase (in):
    70.9
  • Dry Weight (lbs):
    692
  • Fuel Capacity (gal):
    4.1
  • Engine Displacement to Weight (cc):
    2.68
• SUSPENSION

  add remove
  • Front Suspension Type:
    Telescopic Fork
  • Front Suspension Size (in):
    1.8
  • Front Travel (in):
    5.1
  • Front Adjustable Fork Pre-Load:
    Yes
  • Front Adjustable Rebound Damping:
    No
  • Front Central Suspension Strut:
    No
  • Steering Damper:
    No
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Rear Travel (in):
    3.5
  • Number Rear Shock Absorbers:
    1
  • Rear Suspension Material:
    Aluminum
  • Air Adjustable:
    No
• WHEELS & TIRES

  add remove
  • Wheels Composition:
    Aluminum
  • Tube / Tubeless:
    Tubeless
  • Tires:
    Standard
  • Front Tire (Full Spec):
    120/70-21
• BRAKES

  add remove
  • Front Brake Type:
    Dual Hydraulic Disc
  • Front Brake Diameter (in):
    11.7
  • Rear Brake Type:
    Hydraulic Disc
  • Rear Brake Diameter (in):
    12.2
  • Regenerative Braking:
    Not Available
  • Regenerative Deceleration:
    Not Available
• SEATS

  add remove
  • Seat Type:
    Two-Piece
  • Seat Location:
    Driver and Passenger
  • Seat Specifications:
    Standard
  • Seat Height (in):
    27.3
  • Number Of Seats:
    2
  • Detachable Passenger Seat:
    Standard
  • Seat Backrest:
    Optional
  • Grab Rail or Strap:
    Standard
