Specifications

• ENGINE

  add remove
  • Engine Type:
    Single-Cylinder
  • Engine Stroke:
    4-Stroke
  • Bore (in):
    3.5
  • Stroke (in):
    2.36
  • Displacement (cc):
    373
  • Horsepower (bhp):
    44
  • Compression Ratio:
    12.6:1
  • Torque (Ft Lbs):
    27.3
  • Torque (Nm):
    37
• TRANSMISSION

  add remove
  • Transmission:
    Standard
  • Transmission Type:
    Manual
  • Primary Drive (Rear Wheel):
    Chain
  • Number Of Speeds:
    6
  • Final Drive Ratio:
    2.67
  • Overdrive:
    Yes
  • Gear Ratio (1):
    2.67
  • Gear Ratio (2):
    1.86
  • Gear Ratio (3):
    1.42
  • Gear Ratio (4):
    1.14
  • Gear Ratio (5):
    0.96
  • Gear Ratio (6):
    0.84
• TECHNICAL SPECIFICATIONS

  add remove
  • Wheelbase (in):
    52.8
  • Ground Clearance (in):
    6.2
  • Ground Clearance (mm):
    158
  • Dry Weight (lbs):
    341.7
  • Fuel Capacity (gal):
    3.6
  • Fuel Capacity (l):
    13.7
  • Engine Displacement to Weight (cc):
    1.09
• SUSPENSION

  add remove
  • Front Suspension Type:
    Inverted Fork
  • Front Suspension Size (in):
    1.7
  • Front Travel (in):
    4.7
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Rear Travel (in):
    5.9
  • Number Rear Shock Absorbers:
    1
  • Front Suspension Brand Name:
    WP APEX
  • Rear Suspension Brand Name:
    WP APEX
• WHEELS & TIRES

  add remove
  • Front Tire Width:
    110
  • Front Wheel Diameter:
    17
  • Rear Wheel Diameter:
    17
  • Front Tire (Full Spec):
    Continental ContiRoad 110/70 ZR17
  • Rear Tire (Full Spec):
    Continental ContiRoad 150/60 ZR17
  • Rear Tire Width:
    150
  • Front Tire Aspect Ratio:
    70
  • Rear Tire Aspect Ratio:
    60
• BRAKES

  add remove
  • Front Brake Type:
    Disc
  • Front Brake Diameter (in):
    12.6
  • Rear Brake Type:
    Disc
  • Rear Brake Diameter (in):
    9.1
