The 2026 Harley-Davidson® Sportster® S is designed as a performance-focused motorcycle built around the Revolution® Max 1250T engine platform. The model combines a compact chassis structure, advanced rider assistance systems, adjustable suspension components, and integrated electronic technology. The 2026 Harley-Davidson® Sportster® S uses a liquid-cooled engine configuration and a modern structural design that differs from previous air-cooled Sportster® models. Technical specifications show a motorcycle engineered for strong acceleration, controlled handling, and consistent rider feedback through electronic systems and mechanical components.
The motorcycle measures 89.4 inches in length, 33.1 inches in width, and 42.7 inches in overall height. The wheelbase is 59.8 inches, contributing to compact proportions and responsive steering characteristics. Laden seat height is listed at 28.9 inches, while unladen seat height measures 30.1 inches. Static ground clearance is 3.5 inches. Steering geometry includes a 30-degree rake, a 28-degree fork angle, and 5.8 inches of trail.
Revolution® Max 1250T Engine Configuration
The 2026 Harley-Davidson® Sportster® S uses the Revolution® Max 1250T engine, a liquid-cooled V-twin powertrain with a displacement of 1,252 cc or 76.4 cubic inches. The engine features a bore of 4.134 inches and a stroke of 2.846 inches. The compression ratio is rated at 12.0:1. The engine configuration includes chain-driven dual overhead camshafts, hydraulic self-adjusting lifters, variable valve timing on intake and exhaust valves, and four valves per cylinder.
Electronic Sequential Port Fuel Injection manages fuel delivery. The intake system uses a downdraft intake arrangement with tuned velocity stacks and washable filter media. The exhaust system uses a 2-into-1-into-2 layout with a catalyst integrated into the muffler assembly. Lubrication is managed through a semi-dry sump system.
Performance figures indicate output of 121 horsepower at 7,500 rpm and 93 ft-lb of torque at 6,000 rpm. Torque values are measured using the J1349 testing method. The engine characteristics support strong mid-range acceleration and high-rpm power delivery. The liquid-cooling system assists with thermal management during extended operation and varying riding conditions.
Transmission and Drivetrain Specifications
The 2026 Harley-Davidson® Sportster® S uses a 6-speed transmission paired with a mechanical assist-and-slip clutch. The clutch uses an 8-plate wet design rated at 1090N. The assist mechanism reduces clutch lever effort during operation, while the slip function helps maintain rear-wheel stability during aggressive downshifting.
Primary drive ratio is listed at 49/89 through a gear-driven system. Final drive uses a belt system with a 34/80 ratio. Belt final drive systems reduce maintenance requirements compared to chain-driven alternatives while supporting smooth power transfer.
Overall gear ratios are 12.21 in first gear, 9.022 in second gear, 6.994 in third gear, 5.641 in fourth gear, 4.731 in fifth gear, and 4.131 in sixth gear. The ratio spacing supports acceleration through lower gears and reduced engine speed during highway cruising in higher gears.
Chassis Engineering and Structural Design
The frame uses a stressed-member configuration with a high-strength low-alloy steel trellis structure. Construction includes stamped, cast, and forged junctions joined through MIG welding. An aluminum forged mid-structure contributes to weight distribution and structural rigidity. The stressed-member design allows the engine to function as part of the chassis structure, reducing additional frame mass.
The swingarm uses high-strength low-alloy steel with tubular sections, forged axle junctions, and a stamped cross-member structure. MIG welding is also used in the swingarm assembly. These structural components are intended to maintain chassis rigidity during acceleration, braking, and cornering loads.
The motorcycle has a running-order weight of 502 pounds and an as-shipped weight of 487 pounds. Gross Vehicle Weight Rating is listed at 922 pounds. The Front Gross Axle Weight Rating is 359 pounds, while the rear Gross Axle Weight Rating is 595 pounds.
Suspension Components and Ride Control
Front suspension uses a 43 mm inverted fork with adjustable compression damping, rebound damping, and spring preload. Aluminum fork triple clamps are included in the assembly. Inverted fork designs increase rigidity under braking and cornering loads by placing larger diameter fork tubes near the upper triple clamp area.
Rear suspension consists of a linkage-mounted piggyback monoshock with adjustable compression damping, rebound damping, and hydraulic spring preload adjustment. The linkage-mounted design changes leverage rates through suspension travel to support control during varying riding conditions.
Front suspension travel measures 3.6 inches, while rear suspension travel measures 3.2 inches. Combined with the motorcycle’s geometry and wheelbase, the suspension configuration is intended to balance stability and responsiveness.
Wheel Construction and Tire Specifications
The 2026 Harley-Davidson® Sportster® S uses cast aluminum wheels finished in satin black. The front wheel measures 17 inches in diameter and 4.5 inches in width. The rear wheel measures 16 inches in diameter and 5 inches in width.
Front tire specification is 160/70R17 73V using the Dunlop® Harley-Davidson® Series GT503 radial tire. Rear tire specification is 180/70R16 77V using the same tire model line. The tire dimensions support traction during acceleration and cornering while maintaining load-carrying capability.
Lean angle ratings are listed at 35 degrees on both the right and left sides under J1168 testing standards. These measurements indicate the available cornering clearance before hard-part contact occurs.
Braking Hardware and Electronic Brake Control
Front braking uses a radially mounted monoblock 4-piston caliper paired with a single floating rotor. Rear braking uses a floating single-piston caliper with a solid, uniform expansion rotor. The front rotor diameter measures 12.6 inches with a thickness of 0.2 inches. Rear rotor diameter measures 10.2 inches with a thickness of 0.2 inches.
The motorcycle includes standard Anti-lock Braking System functionality. Cornering Enhanced Anti-lock Braking System is also included. These systems monitor wheel behavior during braking and adjust braking force to reduce wheel lock conditions during straight-line and leaned-over operation.
Electronic Linked Braking is not included on this model. The braking package instead focuses on rider-controlled brake input supported by electronic intervention systems designed to maintain stability and traction.
Rider Safety Enhancement Systems
The 2026 Harley-Davidson® Sportster® S includes multiple electronic rider assistance systems integrated into the motorcycle’s control architecture. Standard systems include the Traction Control System, the Drag-torque Slip Control System, the Tire Pressure Monitoring System, and the Wheel Lift Mitigation.
Cornering Enhanced Traction Control System adjusts intervention characteristics during leaned-over riding conditions. Cornering Drag-torque Slip Control System assists with rear-wheel behavior during aggressive downshifts while cornering. Enhanced Lift Mitigation monitors front-wheel lift tendencies during acceleration and modifies engine response as required.
Tire Pressure Monitoring System continuously monitors tire inflation levels and provides rider feedback through the display system. These electronic systems are designed to support stability and traction management during varying road and weather conditions.
TFT Display and Integrated Technology
Instrumentation is centered around a 4-inch TFT color display with a 102 mm viewable area. The display includes speedometer, tachometer, gear position indicator, odometer, fuel level, trip information, ambient air temperature, low-temperature alert, side-stand alert, tip-over alert, cruise indication, and fuel range information.
Bluetooth® capability allows phone pairing for calls, music access, and navigation functions through the Harley-Davidson® application platform. Hands-free mobile phone capability through Bluetooth® is standard equipment. Bluetooth® media support is also included.
The information screen can display Tire Pressure Monitoring System information, engine temperature, battery voltage, and ambient air temperature. USB-C charging and instrument updates are supported through a 5V, 3A USB-C connection. Navigation functionality is available through Bluetooth® connectivity and the associated application interface.
The infotainment section does not list integrated speakers, radio functionality, or built-in audio output systems. Rider and passenger intercom capability is limited to headset function support through Bluetooth® connection.
Electrical System and Lighting Equipment
Electrical power is supplied by a sealed maintenance-free absorbed glass mat battery rated at 12V and 12Ah with 225 cold-cranking amps at 0°F. Charging is managed through a three-phase 45-amp system producing 300 watts at 13 volts and 1,200 rpm. Maximum output is listed at 585 watts at 13 volts and 2,250 rpm.
Starting uses a 0.9 kW electric starter motor with direct-drive engagement. The electrical system supports the motorcycle’s TFT instrumentation, rider safety electronics, LED lighting components, and charging functions.
Lighting equipment includes an all-LED headlamp assembly with low beam, high beam, and signature position lighting. Rear lighting uses all-LED tail and stop lamps. Front and rear turn signals use LED Bullet Turn Signals. LED lighting systems reduce electrical demand while providing consistent illumination characteristics.
Fuel Capacity and Efficiency Metrics
Fuel capacity for the 2026 Harley-Davidson® Sportster® S is listed at 3.1 gallons, with reserve fuel capacity measured at 0.8 gallons. The estimated combined city and highway fuel economy is rated at 49 mpg or 4.8 liters per 100 kilometers.
Oil capacity with filter replacement is listed at 4.75 quarts. Coolant system capacity measures 2.32 quarts. These specifications define fluid requirements for routine maintenance intervals and standard operating conditions.
The service schedule specifies an initial service at 1,000 miles, followed by maintenance intervals every 5,000 miles. Additional inspections for certain systems and components are required at 2,500-mile intervals.
